Blackmagic Design Cloud Store Max 24TB Blackmagic Design
Kód: ADWCLDF/CLDMAX24XSúvisiaci tovar
Podrobný popis
Blackmagic Cloud Store Max 24TB is an extremely high-performance flash storage unit in a compact 1RU rack design. Twelve M.2 NVMe cards in a RAID 0 array, four 10G Ethernet ports and a 100G Ethernet QSFP28 port give up to 200 computers access to large projects, the built-in LCD and the SDI and HDMI outputs show the status, and synchronization with Blackmagic Cloud connects remote teams.
1RU flash storage with a 100G port for demanding teams
Twelve M.2 NVMe cards in RAID 0, four 10G Ethernet ports and QSFP28 100G in a compact 1RU chassis.
Fast even with dozens of users
The storage shares files over SMB and NFS with up to 200 computers. The QSFP28 port connects the storage to high-speed infrastructure over copper cables or longer optical fiber.
LCD and spin knob
The built-in 2.2 inch color display, three buttons and a spin knob are used for settings and show the storage name, capacity and use.
Synchronization with Blackmagic Cloud
Selected folders synchronize with Blackmagic Cloud for global distribution of files, and synchronization with Amazon Web Services S3 is supported as well.
Four 10G ports, 100G and USB-C
The four 10G Ethernet ports serve workstations, the 100G QSFP28 port connects the storage to a high-speed network and the USB-C port with Ethernet over USB allows a laptop to connect directly. The Blackmagic Cloud Setup Utility handles configuration and updates.
Storage status on a monitor
The SDI and HDMI monitor outputs show the device name, storage capacity and use, Cloud Sync status, user activity, hardware status, a storage map and network data rate graphs.
Connector overview
The diagram shows the USB-C port and the controls on the front panel and, on the rear panel, the AC power input, the +12V DC input, the 100G Ethernet port, the four 10G Ethernet ports and the SDI and HDMI monitor outputs.
- Blackmagic Cloud Store Max 24TB
- Welcome wallet with QR code for software download
- Type: network storage, 1RU rack mount
- Capacity: 24 TB
- Memory: 12× M.2 NVMe SSD, RAID 0
- 10G Ethernet ports: 4× RJ45, 100/1000/10G BASE-T
- 100G Ethernet port: 1× QSFP28
- USB-C port: 1× USB 3.0 (up to 5 Gb/s), supports Ethernet over USB
- Monitor outputs: 1× SDI, 1× HDMI, 1080p50/59.94/60
- Display and control: built-in 2.2 inch color LCD, three buttons and a spin knob
- File sharing: SMB, NFS
- Connected computers: up to 200
- Cloud synchronization: Blackmagic Cloud, Amazon Web Services S3
- Power: internal 100–240 V AC, 50/60 Hz power supply, IEC C14 mains input; 4-pin XLR +12 V DC input
- Power consumption: 150 W
- Software included: Blackmagic Cloud Setup Utility, Blackmagic Proxy Generator Lite
- Supported systems: macOS 15 Sequoia, macOS 26 Tahoe or later, Windows 10 (64-bit) and Windows 11
- Dimensions (W × D × H): 19 × 9.25 × 1.74″ (483 × 235 × 44 mm)
- Weight: 6.31 lb (2.86 kg)
- Operating temperature: 0 to 40 °C
- Storage temperature: −20 to 60 °C
- Relative humidity: 0 to 90 % non-condensing
- Warranty: 1 year limited manufacturer’s warranty
Dodatočné parametre
| Kategória: | Ostatné pamäťové média |
|---|---|
| Záruka: | 2 roky |
| EAN: | 9338716008876 |
| Kapacita: | 4TB |
| Položka bola vypredaná… | |
