DZOFILM X-tract 18–28 mm T8 is a modular full-frame macro probe zoom with a PL mount. This kit combines 0° / 90° / 360° viewing-angle modules with one interchangeable R unit, letting you change perspective while retaining the same 18–28 mm zoom, T8–T45 aperture and cine controls. It covers a 43.2 mm image circle, reaches a 6 mm working distance and up to 2.1× magnification at 28 mm for detailed product, tabletop and creative work in confined spaces.

DZOFILM X-TRACT

MODULAR MACRO PROBE ZOOM

DZOFILM X-tract 18–28 mm T8 is a modular full-frame macro probe zoom with a PL mount. This kit combines 0° / 90° / 360° viewing-angle modules with one interchangeable R unit, letting you change perspective while retaining the same 18–28 mm zoom, T8–T45 aperture and cine controls. It covers a 43.2 mm image circle, reaches a 6 mm working distance and up to 2.1× magnification at 28 mm for detailed product, tabletop and creative work in confined spaces.

CHANGE THE ANGLE, KEEP THE WORKFLOW

The 0°, 90° and 360° system opens up direct, periscope and rotating perspectives. The optics retain focus through zooming, while the 300° manual throw supports precise follow-focus work. DZOFILM notes that footage from the 90° module requires a mirror flip.

MACRO IN CONFINED SPACES

Focus begins at 0.47 m from the sensor plane, while the working distance in front of the lens is just 6 mm. With up to 2.1× magnification at 28 mm, it can capture fine textures, liquids and miniatures from extremely close range.

CONSTRUCTION AND MODULES

These detail images show X-tract's interchangeable probe modules. The 0°, 90° and 360° options change perspective while the 18–28 mm zoom and cine controls remain consistent.

DETAIL AND PERSPECTIVE

A 6 mm working distance and up to 2.1× magnification at 28 mm let the camera move extremely close to a surface while retaining control of the shot.

0° MODULE IN USE

This photograph shows a working rig with the direct-view 0° module included in this kit. It illustrates the position of the front element at the subject; it is not footage recorded by the lens.

90° MODULE IN USE

This photograph shows a working rig with the 90° module included in this kit. It illustrates the position of the front element at the subject; it is not footage recorded by the lens.

Official X‑tract image sample

This frame comes from DZOFILM’s official X‑tract series image samples. It demonstrates the probe system’s imaging character; it is not a test of this exact three-module kit.

• 1× removable X-tract lens assembly with R unit
• 1× 0° straight tube
• 1× 90° periscopic tube
• 1× 360° periscopic tube
• 1× 15mm follow-focus rod with mounts
• 1× front cap
• 1× rear cap
• 1× large 1.8″ quick-release O-clamp
• 2× small 1.2″ quick-release O-clamps
• 2× set of spacer washers
• 1× UV filter No. 1
• 1× UV filter No. 2
• 1× hard case with foam insert

• Type: modular full-frame macro probe zoom
• Focal length: 18–28 mm
• Modules in the set: 0° / 90° / 360°
• Mount: PL; flange distance 52 mm
• Aperture: T8–T45; 10 blades
• Image circle: Ø 43.2 mm
• Optical design: 0°: 25 elements / 18 groups; 90°: 26 / 19; 360°: 27 / 20
• Closest focusing distance: 0.47 m from the sensor plane; working distance 6 mm
• Zoom / magnification: 1.55× zoom ratio; maximum 2.1× at 28 mm
• Controls: focus 300° / zoom 100° / aperture 72°; 0.8 MOD
• Front element: 0° Ø 29.6 mm; 90° and 360° 37.7 × 30.58 mm
• Construction: aluminum alloy; parfocal design
• Probe durability: hydrophobic front coating; submersible up to 28 cm
• Rear element protrusion: 13.7 mm beyond the bayonet mount
• 90° module view: images require mirror reversal
• Assembled configuration weight: approximately 1,090 g (0°), 1,132 g (90°), 1,144 g (360°)
• Net weight of the entire set: the manufacturer does not publicly list this for this SKU
