Viltrox DC-550 Lite Viltrox

Podrobný popis

Viltrox DC‑550 Lite is a compact 5.5-inch Full HD on-camera monitor with a 1,920 × 1,080 IPS display, 400 cd/m² brightness and a wide viewing angle. Its HDMI 1.4 input and loop-through output accept signals up to 4K/30p, giving filmmakers a larger, more precise view without interrupting camera recording. Button control, histogram and waveform help with exposure, the 3.5 mm socket supports audio monitoring, and firmware can be updated via SD card. Power is available from a Sony NP-F battery, 12–18 V DC input or USB-C at 5 V / 3 A.

Full HD camera monitor

Viltrox DC‑550 Lite

This lightweight monitor adds a 5.5-inch IPS screen, Full HD resolution and clear physical controls to a camera rig. It is made for filmmakers who need a more confident view of framing, focus and exposure in a compact setup.

5.5″ Full HD400 cd/m²HDMI up to 4K/30p

Direct monitoring

Lite is the button-controlled version of the DC-550 family. Histogram and waveform help check exposure, while the wide viewing angle keeps the image readable away from centre.

Uninterrupted HDMI

HDMI 1.4 input and loop-through output support a 4K signal up to 30p. Monitor a camera while passing the image onward to another compatible device.

Field-ready power

Use a Sony NP-F battery for mobile work, or power the monitor through 12–18 V DC or USB-C at 5 V / 3 A. A 3.5 mm output supports headphones and the SD-card slot is used for firmware updates.

• Viltrox DC‑550 Lite monitor with sun hood ×1
• NP-F550 battery ×1
• Cold-shoe adapter ×1
• USB-C cable ×1
• Standard-to-mini HDMI cable ×1
• Standard-to-micro HDMI cable ×1
• Carry case ×1
• User manual ×1

• Display: 5.5″ IPS LCD
• Resolution: 1,920 × 1,080 (Full HD)
• Brightness: 400 cd/m²
• Viewing angle: wide
• Video input/output: HDMI 1.4, up to 4K/30p
• Audio: 3.5 mm headphone output
• Control: physical buttons
• Monitoring: histogram and waveform
• Firmware: SD-card update
• Power: NP-F, 12–18 V / 2 A DC or USB-C 5 V / 3 A
• Dimensions: 165 × 91 × 28.5 mm
• Weight: approx. 267 g
